The purpose of this feature is to give scout leaders, educators and naturalists an idea of some of the natural events coming up each month. We will try to cover a variety of natural events ranging from sky events to calling periods of amphibians, bird and mammal watching tips, prominent wildflowers and anything else that comes to mind. We will also note prominent constellations appearing over the eastern horizon at mid-evening each month for our area for those who would like to learn the constellations. If you have suggestions for other types of natural information you would like to see added to this calendar, let us know!

Note: You can click on the hyperlinks to learn more about some of the featured items. To return to the Calendar, hit the "back" button on your browser, NOT the "back" button on the web page. All charts are available in a "printer friendly" mode, with black stars on a white background. Left clicking on each chart will take you to a printable black and white image. Please note that images on these pages are meant to be displayed at 100%. If your browser zooms into a higher magnification than that, the images may lose quality.

Though we link book references to nationwide sources, we encourage you to support your local book store whenever possible.

Notes and Images From July 2013

Brown Stink Bug, July 31st, Nikon D5100 Camera and reversed 50mm Lens with 68mm Extension. Click on the image above to see a high resolution version.

In the June 2013 Natural Calendar we talked about the small depths of field involved in high magnification macro imaging. On July 31st I finally got a chance to try out my little home made focusing rail. A stepper motor automatically moves the camera along the rail in small increments to make a number of exposures, gradually moving the focal plane through the subject. Then the sharpest areas of each image are combined to make one image with an enhanced depth of field.

Since the only insect I had available between rain showers was this Brown Stinkbug, it became my first test subject. It obligingly remained in position while the rail made 23 images. The individual images were then combined with masks in Photoshop. To really appreciate the level of detail, click on the image above to see a larger version.

Stink bugs are considered pests and are capable of doing a lot of damage to agricultural crops. The get the name from the fowl odor that they emit if you pick them up. Structurally they are quite interesting, with a long articulated feeding tube that they use to tap their food source and drink its juices.

Sky Events for August 2013:

Evening Sky:

Saturn, February 13th, 2013. Twenty Inch Newtonian Reflector

Saturn is low in the southwest in the early evening at the beginning of August, about 30 degrees above the southwest horizon, in Virgo. The rings are open to around 19 degrees, giving a beautiful view of the very dark Cassini's Division. This is a terrific time to view Saturn in any size telescope. Be sure to start your observing early in the evening, before it sinks closer to the horizon.

Bright Venus decorates the sky at dusk throughout August. Look for it low in the western sky about 30 minutes after sunset.

Morning Sky:

Jupiter, February 24th, 2013. Twenty Inch Newtonian Reflector

Jupiter rises around 3:30am at the beginning of the month in Gemini, followed about 20 minutes later by Mars. Telescopically, Mars is still tiny, only about 4 seconds of an arc in apparent diameter.

Mercury can be seen below Mars in the eastern dawn sky during the first half of the month. It sinks closer to the horizon each morning. Binoculars are helpful in spotting the fleet-footed planet.

All times noted in the Sky Events are for Franklin, Tennessee and are Central Daylight Time. These times should be pretty close anywhere in the mid-state area.

Messier 15, September 24, 2009. Six Inch Apochromatic Refractor and ST-2000 CCD Camera.

Constellations: The views below show the sky looking east at 10:00pm CDT on August 15th. The first view shows the sky with the constellations outlined and names depicted. Star and planet names are in green. Constellation names are in blue. The second view shows the same scene without labels. New constellations this month are Pegasus, the Flying Horse, Andromeda, Princess Andromeda, Triangulum, the Triangle, Pisces, the Fishes, and Aquarius, the Water Bearer.

In Pegasus, the reddish star Enif marks the nose of the flying horse. Just above Enif is the globular cluster Messier 15, a nice ball of stars about 33,600 light-years away. The cluster was discovered by Jean Dominique Maraldi on September 7th, 1746. Maraldi was searching for De Chéseaux' Comet at the time.

This globular cluster is one of the densest known in our Milky Way galaxy. It contains nine known pulsars. As with any deep sky object, you should wait until it has climbed high above the horizon to get the best telescopic view. It is easily visible in binoculars, and is said to be visible to the naked eye under really dark skies.

In a small telescope it will appear like a little cotton ball of faint light. With increasing aperture, you'll be able to spot some of the faint stars around the periphery of the cluster. Be sure to use averted vision, looking to one side of the cluster, to allow the cluster's light to fall on the light-sensitive rod cells of your eye.

August 15th, 10:00pm CDT, Looking East

On Learning the Constellations:

We advise learning a few constellations each month, and then following them through the seasons. Once you associate a particular constellation coming over the eastern horizon at a certain time of year, you may start thinking about it like an old friend, looking forward to its arrival each season. The stars in the evening scene above, for instance, will always be in the same place relative to the horizon at the same time and date each August. Of course, the planets do move slowly through the constellations, but with practice you will learn to identify them from their appearance. In particular, learn the brightest stars for they will guide you to the fainter stars. Once you can locate the more prominent constellations, you can "branch out" to other constellations around them. It may take you a little while to get a sense of scale, to translate what you see on the computer screen or what you see on the page of a book to what you see in the sky. Look for patterns, like the stars that make up the "Square of Pegasus."

The earth's rotation causes the constellations to appear to move across the sky just as the sun and the moon appear to do. If you go outside earlier than the time shown on the charts, the constellations will be lower to the eastern horizon. If you observe later, they will have climbed higher.

As each season progresses, the earth's motion around the sun causes the constellations to appear a little farther towards the west each night for any given time of night. If you want to see where the constellations in the above figures will be on September 15th at 10:00pm CDT, you can stay up till midnight on August 15th and get a preview. The westward motion of the constellations is equivalent to two hours per month.

Recommended:

Sky & Telescope's Pocket Star Atlas is beautiful, compact star atlas.

A good book to learn the constellations is Patterns in the Sky, by Hewitt-White. You may also want to check out at H. A. Rey's classic, The Stars, A New Way to See Them.

For skywatching tips, an inexpensive good guide is Secrets of Stargazing, by Becky Ramotowski.

A good general reference book on astronomy is the Peterson Field Guide, A Field Guide to the Stars and Planets, by Pasachoff. The book retails for around $14.00.

Starry Night has several software programs for learning the night sky. Visit the Starry Night web site at www.starrynight.com for details.

The Virtual Moon Atlas is a terrific way to learn the surface features of the Moon. And it's free software. You can download the Virtual Moon Atlas here.

Cartes du Ciel (described in the monthly notes above) is a great program for finding your way around the sky. It is also free, and can be downloaded here.

Apps: We really love the Sky Safari 3 Pro application described here. For upcoming events, the Sky Week application is quite nice. Both apps are available for both I-phone and Android operating systems.

Insects:

Northern True Katydid, July 18th, Nikon D40x Camera and Nikon Micro 105mm Lens. Thanks to Sophia for helping make this image and the image below possible! The Katydid is a leaf mimic. Compare the patterns in the Katydid's wings to the leaflet at lower right.

For many people, one of the defining sounds of a summer night is the rhythmic chanting of katydids.

For me the sound evokes memories of summer vacations when I was a kid. Our family often drove at night along state highways. The interstate system was still yet to come. Our car, like most cars then, did not have air conditioning, so the windows were down. As the highway wound through patches of forest the katydid calls grew louder, enveloped the car, then faded away. My brother and I stretched out on beds our parents made for us on the back seat and floor (no seatbelts then.) We drifted off to sleep to the comforting murmur of our parents' voices and the calls of the katydids, a lullaby.

Northern True Katydid, July 18th, Nikon D40x Camera and Nikon Micro 105mm Lens.

The eyes of katydids are stunning, with the upper part yellow and the bottom a rich green. Only the males have the purple "cap."

Katydids belong to the family Tettigoniidae. The call that is probably best known is that of the Northern True Katydid. It's in the subfamily Pseudophyllinae, and the species name is Pterophylla camellifolia. It ranges over most of the eastern United States.

Northern True Katydids typically call from fairly high in the tree canopy, making them difficult to spot. The genus name, Pterophylla, literally means "wing leaf" and they are amazing leaf mimics. Compare the pattern in the katydid's wings in the top image above to the patterns in the leaflet in the lower right hand corner of the image.

Northern True Katydids produce sounds by rubbing a sharp "scraper" at the base of one wing against a file-like row of "teeth" at the base of the other wing. Sometimes in large choruses the calls become synchronized. In this recording we made at Franklin State Forest in Marion County, a Northern True Katydid close to the microphone begins calling. Note how its call becomes synchronized with the ongoing chorus.

Oblong-winged Katydid, Male Yellow form, July 4th, 2011, Nikon D40x and Nikon 105mm Micro Lens

The False Katydids are in the subfamily Phaneropterinae. One common member of this subfamily is the Oblong-winged Katydid. These katydids have wings that are more elongated than the Northern True Katydid, and the call is a short raspy sound only about a third of a second long.

The call sounds a little like a match being struck. In this recording Northern Cricket Frogs are heard calling in the background. The katydid gives only a single note. Oblong-winged Katydids usually are a bright green color, but can also occur in the yellow form shown in the image at left. We find the yellow form to be rarer. Pink forms have also been found.

Robust Conehead, Neoconocephalus robustus, Male, July 25th, 2009. Green color phase in head-down calling position. Nikon D40x and 105mm Micro Lens.

The calls of coneheads are conspicuous on midsummer evenings. They call most frequently during July and the first part of August. Two common species of coneheads in Tennessee are the Robust Conehead and the Nebraska Conehead. Both species can be either green or a brown in color. Both usually call from weedy vegetation with their head down, as shown in the image at right, ready to drop into the ground cover if alarmed.

Coneheads are in the katydid family (Tettigoniidae), which also includes the True Katydids, the Meadow Katydids, the Shieldback Katydids and the False Katydids. The genus is Neoconocephalus.

The easiest way to locate coneheads is by listening for their calls. Just drive a few back roads that pass by weedy fields at dusk or later and you should hear them. The Robust Conehead is the larger of the two species and is between two and three inches long. It has a very long, rasping call on one pitch. Like a bad musician, it seems to try to make up in sheer volume what its song lacks in complexity. As you drive by you can sometimes hear the call doppler-shifting downward. The call has a peak frequency of around 8 kHz, and you can listen to one we recorded by clicking here. There are two cuts - the first cut records the sound as you might hear it at a distance, and includes Common True Katydids in the background. The second cut records the sound as you might hear it if one is calling right beside the road.

Nebraska Conehead, Male, July 31st, 2009. Brown color phase. Nikon D40x and 105mm Micro Lens.

The name Nebraska Conehead is a little misleading, as the range of this species also includes a wide area of the eastern United States. A little smaller than the Robust Conehead, it measures between 1-3/4 inches to 2-1/4 inches in length. The call of the Nebraska Conehead is also a raspy note on one pitch, but the length of each call lasts only between 1-1/2 to 2 seconds, with a pause of about one second in between calls. Its call peaks around 10 kHz. To listen to a recording of a Nebraska Conehead that we made last summer, click here.

Seen close up, the eyes of both species are quite interesting. If you happen across a conehead that is not calling, look carefully at the underside of the cone and observe how it is marked. These markings are a useful way to distinguish between species. See the reference at the bottom of this section for help in identification.

Columbian Trig, Male, July 15th, 2011, Nikon D40x and Nikon 105mm Micro Lens

The trigs form another interesting group. These small crickets belong to the subfamily Trigonidiinae (hence the name). They are also known as the sword-tailed crickets. Shown at right is the Columbian Trig. Only about 1/4 of an inch long, these tiny crickets make sounds that many people have heard all their life without knowing the identity of the caller.

A chorus has the rhythmic quality of sleigh bells. Because they tend to blend in with the other sounds of a summer night, you may have to concentrate to pick them out of the many other insect noises on a typical July or August night. We made this recording in our front yard, and since seem to hear them everywhere we go.

Large Milkweed Bugs mating on Butterfly Weed Leaf, July 25th, 2009. Nikon D40x and 105mm Micro Lens.

By day, some of the more colorful insects can be found in patches of milkweed. Monarch butterflies lay their tiny cream-colored eggs on the milkweed leaves and you can usually find a Monarch caterpillar munching on the foliage. If you’re lucky, you might even find the beautiful, jewel-like chrysalis of the Monarch nearby. To see a complete image sequence of a Monarch caterpillar forming its chrysalis and emerging as a butterfly, click here. Scarlet and Green Leafhoppers, Large Milkweed Bugs and Red Milkweed Beetles all add their brilliant warning colors to the scene.


Scarlet and Green Leafhopper	Red Milkweed Beetle	Monarch Emerging From Chrysalis	Large Milkweed Bug

To learn more about insects and insect songs we recommend:

Books:

The Songs of Insects, by Lang Elliott & Will Hershberger (Houghton Mifflin) - Beautifully written and including many spectacular images, this book includes an audio CD and detailed range maps. It was a real bargain for $19.95, and you can now get it from Amazon for less than $14.00.

Crickets and Katydids, Concerts and Solos, Vincent G. Dethier (Harvard University Press) - In this book Vincent Dethier writes of his experiences in the 1930's working as a field assistant gathering insects so that their songs could be recorded and analyzed. Now out of print, you should still be able to locate a copy by clicking the link above. An inspiring book and one of our favorites.

Online:

Singing Insects of North America - This is a terrific online reference.

Songs of Insects - Another great reference from Lang Elliott and Will Hershberger.

Amphibians:

Green Frog

Listen for Cope's Gray Treefrogs, Gray Treefrogs, Bird-Voiced Treefrogs, Green Treefrogs and Barking Treefrogs. Northern Cricket Frogs and Southern Cricket Frogs are still calling, as are American Bullfrogs and Green Frogs. Spring Peepers have a much higher, shorter call this time of year. On cooler nights listen for American Toads, but be wary of the many calling crickets this time of year. After heavy rains listen for the high, insect-like call of the Eastern Narrow-mouthed Toad and the strange-sounding Eastern Spadefoot.

Recommended: The Frogs and Toads of North America, Lang Elliott, Houghton Mifflin Co.
